Mitsubishi VHS-C Video Camera -Recorder HS-CX4 - Full Specs and Features
Learn more about the specs and features of the Mitsubishi VHS-C Video Camera -Recorder HS-CX4 :
Tape Format VHS-C 1/2' high-density video cassette tape
Power Source DC 6.0V
Power Consumption : Approx. 6.4W[CX4], 5.8VVICX11
Signal System PAL System
Video Recording System Azimuth helical scanning system
Luminance Frequency modulation recording
Color Signal Low frequency conversion subcarrier phase shift recording
Hi-Fi Audio Recording System Azimuth helical scanning system, Frequency modulation, deep layer
recording"
Linear Audio Track : 1 track
Tape Speed 23.39 mm/sec(SP mode), 11.70 mm/sec(LP mode)
Record/Playback Time : 45 min. with EC-45 cassette, (SP mode)
90 min. with EC-45 cassette
(LP mode)
Video Output 1.0 Vp-p,75 ohm unbalanced AV
OUT/EDIT socket
Audio Output -6dBs. 1k ohm unbalanced AV
OUT/EDIT socket
Pick Up 1/3-inch format CCD
Minimum Required Illumination: 5 lux
Lens F1.8, 16-48mm
8:1 power zoom lens with auto iris
control
Filter diameter 49 mm
Viewfinder Electronic viewfinder with 0.6-inch black/
white CRT .
White Balance Adjustment -Full-auto/selectable FIX, INDOOR or
OUTDOOR
Operating Temperature
0°C - +40°C
Operating Humidity : 30% - 80%
Weigh Approx. 590g
Dimensions 105(W) x 112(H) x 155(D)mm
AC POWER ADAPTER DA-M1(A,B,C)
Power Source AC 110 - 240V; 50/60Hz
Power Consumption: Approx. 19W
Rated Output Current1.8A(VIDEO CAMERA/RECORDER),
1.3A(Battery)
Charging System : Constant current, voltage controlled
Dimensions 65(W) x 39.5(H) x 138(D)
