Hidden elevator
Concept sketch of an 1m linear actuator lifting a platform out of the ground.
To be built from 48x48mm wooden slats and 12mm board. The tower is 300x300 wide.
If it is placed outside the hole must be prevented from caving in from the sides and protected from rainwater.
Modelled and animated in Fusion360. 3D Model: https://a360.co/2WVMUcM
Linear actuator: 12V with brackets https://s.click.aliexpress.com/e/cfsN...
Remote control: Order 2 of type B https://s.click.aliexpress.com/e/pV8JwYC
Power supply: 12V 8A EU plug https://s.click.aliexpress.com/e/p3N247A
