Groov EPIC | PAC Controller Setup and Input / Output Sequence Programming Tutorial [Part 1 / 2]

Опубликовано: 12 Апрель 2020
на канале: SolisPLC

4,053

Groov EPIC | PAC Controller Setup and Input / Output Sequence Programming Tutorial

Visit https://SolisPLC.com for more Tutorials, Information & to connect with the Community

We start by creating a new program for our controller; in the “PAC Control” software, these blocks are called “Strategies”. Click on “File”, “New Strategy…” and select a file location.
Once the strategy is created, we need to link it to our controller. Click on “Configure”, “Control Engines…”. From this menu, the user is invited to add a controller that will be programmed and use the strategy. Input the same information we’ve configured during the setup process.

The next step is to add the IO points we have attached to our controller. Depending on what you’ve purchased, the modules may differ. In this tutorial, we’re exploring the groov EPIC Learning Center (Part Number GRV-EPIC-LC) which includes 4 points of IO external to the controller. These cards may be automatically recognized by the controller or manually added. It’s important to understand both as you may not have access to the controller during the development of the software.
