Laser Controller Trocen AWC708C Setup Part 1
In this video, I connect the AWC708C Laser controller to stepper motor drivers, stepper motors, power supplies that power the laser controller and the stepper motors, and limit switches. The initial system resetting function is demonstrated along with a simple explanation of the homing and usage of the limit switches. A file in the controller is also executed to demonstrate the functioning of the stepper motors.
A detailed explanation is also given on the types of stepper motor coil configurations and how to determine the connections without the use of the stepper motor datasheet.
