In this video, I start out trying a experiment that does not work where I try to read the PWM voltage out using the ADC, but the speed that the ADC reads the pin is too fast to discern the PWM output as a voltage (only as a pulse).
I continue with a more promising experiment where I control the PWM using the ADC that is varied with a potentiometer.
