Oil separator replacement 1.8 TFSI Audi A4 B8 / Skoda Octavia / VW Passat / Skoda Superb

Опубликовано: 17 Август 2019
на канале: Mark Bizin
34,634
453

To replace the 1.8 TFSI Audi A4 B8 oil separator, only the Torx T30 is required, you may still need a pushing flat screwdriver to remove the connectors from the ignition coils
Article NEW oil separator VAG 06H103495AH - purchased for 5680 rubles from the OD Skoda
The article OLD oil separator VAG 06Н103495Е (06H103495A 06H103495AC)
06H103495AH - ONLY suitable FOR 1.8 TFSI, as it creates a vacuum of 25 mbar.

For engines 2.0 TFSI need oil separator VAG 06H103495AJ with a discharge of 100 mbar (old non-manual articles 06H103495AD 06H103495H 06H103495J 06H103495AE 06H103495AK 06H103495AG)
A very useful article where everything is explained in detail https://www.drive2.ru/l/4698674991107...
==============================================
Sequence of steps to replace the 1.8 TFSI oil separator
1) disconnect the ignition coil and Unscrew the mount on the Torx T30
2) remove 2 ignition coils
3) remove the 2 tube ventilation of crankcase gases
4) Unscrew the 10 screws securing the oil separator 1.8 TFSI
5) remove and replace with a new one, the order of tightening the screws as shown in the diagram from ELSA at 5:21 and tighten to the torque of 11 Nm
6) all connect in reverse sequence

After replacement, no difference in engine operation is noticed.
Symptoms in which you need to change the oil separator:
oil consumption
extraneous sounds/whistling when the engine is running
uneven engine operation
==============================================
From observations, with the oil separator 06N103495E at the opening of the oil cover, it was sucked slightly, but the engine began to work unevenly. When switched on 06H103495AH cover began to suck harder, the engine runs unevenly when you open the oil cap.

VAG 06H103495AH for this cars:
Audi - A3 (8P1) A3 Sportback (8PA) A3 Кабриолет (8P7) A4 (8K2, B8) A4 Allroad (8KH, B8) A4 Avant (8K5, B8) A5 (8T3) A5 Sportback (8TA) A5 Кабриолет (8F7) Q5 (8RB) TT (8J3)
Seat - ALTEA (5P1) LEON (1P1) EXEO (3R2) EXEO ST (3R5) TOLEDO III (5P2) ALTEA XL (5P5, 5P8)
Skoda - OCTAVIA II (1Z3) OCTAVIA II Combi (1Z5) SUPERB II (3T4) SUPERB II универсал (3T5) YETI (5L)
Volkswagen - AMAROK (2HA, 2HB, S1B, S6B, S7A, S7B) BEETLE (5C1, 5C2) BEETLE Кабриолет (5C7, 5C8) CC (358) EOS (1F7, 1F8) GOLF V (1K1) GOLF V Variant (1K5) JETTA III (1K2) JETTA IV (162, 163, AV3, AV2) PASSAT (362) PASSAT (3C2) PASSAT ALLTRACK (365) PASSAT CC (357) PASSAT Variant (365) PASSAT Variant (3C5) SCIROCCO (137, 138) TIGUAN (5N_)
==============================================
Blog on DRIVE2 https://www.drive2.com/r/audi/a4/5375...
==============================================
Filmed on Meizu 16th
